Fender Quantum LT 4 USB-C Audio Interface

Quantum LT 4 USB-C Audio Interface

The Fender Quantum LT 4 expands your recording setup with increased I O and flexible connectivity, making it ideal for duos, small ensembles, content creators and growing home studios. Two transparent MAX-HD microphone preamps deliver an impressive 75 dB of gain each, ensuring clean, detailed results with any microphone. Fender-designed instrument inputs provide natural tone for guitars and basses, while balanced TRS outputs and a powerful headphone amp offer versatile monitoring options.

Custom low-latency drivers for macOS and Windows ensure a responsive, professional recording experience. Loopback support simplifies streaming and podcasting, and standalone Mixer Mode allows LT 4 to function as a compact analogue mixer without a DAW. Seamless software integration lets you control monitoring and routing remotely, keeping your workflow fast and intuitive.

Features

• 4 x 2 USB audio interface with custom low-latency drivers for macOS and Windows

• Two MAX-HD microphone preamps with 75 dB of gain for clean, transparent recording

• Dual Fender-designed instrument inputs for guitars, basses and more

• Balanced TRS outputs and powerful headphone amplifier for flexible monitoring

• Integrated line inputs for connecting external gear such as synths and outboard preamps

• Loopback audio for streaming, podcasting and content creation

• Standalone Mixer Mode for computer-free operation

• Software integration with Fender Studio Pro and Universal Control

• Built-in My Fender access for setup, downloads and support

Series

Quantum

Colour

Black

Country Of Origin

CN

Electronics

Inputs

Four - (Two 1/4" TS, Two XLR Combo Mic/Line)

Headphone Jack

Two - 1/4" TRS Female Stereo

Line Out

Two - 1/4" Balanced (Left and Right)

Connectivity

USB-C®

Voltage

120V

Phantom Power

+48 VDC

Performance

Digital Audio Bit Depth

24 Bit

Digital Audio Dynamic Range

115 dB

Inputs

Instrument Input Connection Type

1/4” TS Female, Unbalanced, Hi-Z

Instrument Inputs Frequency Response

20 Hz to 20 kHz

Instrument Inputs Maximum Level

+12.9 dBu

Line Input Connection Type

XLR/TRS Mic/Line Combo

Line Inputs Dynamic Range

115

Line Inputs Frequency Response

20 Hz to 20 kHz

Line Inputs Gain Range

-20 dB to +20 dB

Line Inputs Maximum Level

+15 dBu

Line Inputs Total Harmonic Distortion

0.001%

Microphone Input Connection Type

XLR Female (Combo), Balanced

Microphone Preamp Dynamic Range

115 dB

Microphone Preamp Equivalent Input Noise

-128.9 dBu

Microphone Preamp Frequency Response

20 Hz to 20 kHz

Microphone Preamp Gain Control Range

75 dB

Microphone Preamp Maximum Input Level

+14 dBu

Microphone Preamp Total Harmonic Distortion

0.001%

Outputs

Headphone Outputs Connection Type

Headphone Outputs Dynamic Range

113 dB

Headphone Outputs Frequency Response

20 Hz to 20 kHz

Headphone Outputs Maximum Output

46mW @ THD+N 0.007%

Headphone Outputs Total Harmonic Distortion

0.002%

Main And Line Outputs Dynamic Range

115 dB

Main And Line Outputs Frequency Response

20 Hz to 20 kHz

Main And Line Outputs Maximum Level

+15 dBu (Balanced)

Main And Line Outputs Total Harmonic Distortion

0.002%

Main Outputs Connection Type

1/4" TRS Female
